VX 2200
Digital System“Two wire” BUS audio - “Six wire” BUS video
Art. 8202, 8202R Digital Front Panels
Same features and operation as in the 4000 Series panels but only audio version (for video systems the panel must be combined
with a 8000 Series camera module). These units are built into a double 8000 Series module (stainless steel/S or aluminium/A) and
have numeric keypads and 8 alpha buttons (8202) or a numeric keypad with 3 “Repertory Names” navigation buttons (8202R), 2
x 16 character LCD display and speaker unit.
Art. 8203-0,1,2 - Speaker unit module with functional/Digital Interface
This unit is built into a single 8000 Series module, it includes the speaker and interfaces to the digital bus. Up to 64 push buttons
can be added to the interface using the Art. 8843, 8844, 8845 etc (The 8203 is available with either 1 button, 2 buttons or no
buttons).
Art. VX2204-1, Art. 2204N - 4 way (optional) Isolation Board
This unit isolates the telephones from the main bus preventing a single telephone from compromising the system. One PCB is
required for every four handsets.
Art. VX2206 - Digital BUS Exchanger
For use with two level systems enabling more than one speech path (One per internal block). For videophone systems is required the
VX2206/V.
Art. 2206N - Block exchanger for audio/video door entry systems.
The Art. 2206N has been developed from the Art. 2206A and 2206V (BUS exchange devices) to give greater system flexibility
in one and two level system design and permits far longer cable runs. The 2206N can be used to distribute the system BUS or
used where the installation is greater than 180 apartments. The 2206N allows multiple speech paths on two level systems or on
installations with a main digital entrance panel and a number of digital or functional secondary block or sub entrances with up-
to 998 apartments. This module can also be used on installations where the existing cable cross section is found to be too small.
Note: main door stations used with Art. 2206N must be digital panels (8202 or 4202 and related versions) with firmware release 5.0 or later.
Art. VX2210A-1/A - Digital Concierge Unit for intercom systems
The VX2210 allows the operator to handle and to transfer the calls from and to the users. Depending on the selected operating
mode (day-night-off), it is possible to carry out different functions from the concierge. For videophone systems, it is necessary to
use VX2210-1/V (As VX2210-1/A with additional flat screen monitor). An RS232 input to a PC is also available.
Art. 2211
The Art.2211 is a digital intercom for VX2200 digital system (“2 Wire” BUS audio, “6 Wire” BUS video). The circuitry includes the
same components of the Art.3171B so there are the“door open”&“service”buttons, the electronic call tone (main and local) with
3 adjustable volume levels, the 8 way dip-switch bank to set the intercom address, the board with 6 connection terminals and
the VR1 trimmed to adjust the microphone volume.
Art.2211 allows to operate concierge functions that may be enough for a system having a little number of users.
Art. 2280-1
“2 wire” Bus INTERFACE
The Art. 2280-1 enables the connection of the VIDEX Telephone Interface (Art. 280N1) or the VIDEX PABX interface (Art. 275/2W)
or the VIDEX apartment station (Art. 500MM) onto the VX2200 system“2 wire” Bus. Please, see “Telephone Systems” in this cata-
logue.
Art. 3161B - Intercom
Low cost intelligent intercom with electronic call tone (3 level volume), “door open” and “service” push buttons. It has a reduced
number of features than the 3171B (see VX2200 section). Local bell input (requires an additional wire).
Art. 3171B, 3172, 3176 - Intercoms
Intelligent Intercom with electronic call tone (3 level volume), “door open” and “service” push buttons.
Programmable melody and number of rings. Plus “privacy ON-OFF” switch Art. 3172. Plus “timed privacy ON-OFF” push button,
“door open” LED and “privacy on” LED, Art. 3176.
Art. 5178 - Intercom
Intelligent voice switched hands free intercom with buttons to control “answer/end conversation”, “door open” (programmable
duration), “privacy on/off” (programmable duration) and “service” button. In addition there are 4 LED’s to indicate the status of
“answer/end conversation”, “door open/closed”, “privacy on/off” and auxiliary “service” status. Call tone and loudspeaker volume
controls are also incorporated on this model.
