GENERAL CATALOGUE
The 6000 Series
from Videx, a low cost, easy to use, compact, minimalistic design colour
videophone.
Finished in a satin white and including a 2.4” or 3.5” high definition LCD TFT colour display,
handset and four tactile buttons for door release, door recall and other services such as ‘do not
disturb’ and service buttons depending on the model. The door open and privacy functions are
also accompanied by an indication LED (The door open LED requires an additional connection).
A picture brightness control and call tone volume adjustment is also available to the user while
additional adjustments for picture contrast, hue and on some models microphone volume are
available for the installer.
The 6000 Series (6000, 6200 and 6300)
videophones are low profile surface mount units
containing all the electronics within the body of the unit and all termination connections on
convenient plug type connectors for ease of installation.
Models available are:
--
Art. 6031, 6231 for Videx 4+1 balanced video systems;
--
Art. 6072, 6272, 6378 for Videx VX2200 6 wire bus digital system;
--
Art. 6056, 6256, 6356 for CVK4K, CVK8K and CVR4KV range of video kits;
--
Art. 6286, 6388 for Videx VX2300 2 wire bus digital system.
6000 Series 2.4” videophone with handset
Surface mount only
6200 Series 3.5” videophone with handset
Surface mount only
6300 Series 3.5” hands free videophone
Surface mount only
6000 Series
Videophones
