Art. 5112
Art. 5118N
Art. 5178N
Art. 5188N
Art .VR5178
30
GENERAL CATALOGUE
Art.
HANDS FREE INTERCOMS FOR “4+1” AUDIO DOOR ENTRY SYSTEMS
5112
Simplex intercomwith buttons to control“answer”(press to talk/release to listen),“door open”and 2 ser-
vice buttons. 3 LED’s to confirm the talk/listen status, the open/close door status and the on/off status of
the privacy (no calls). A 3 position call tone volume switch which when in the left position will enable the
privacy function (no calls), in the centre position low volume and in the right position high volume.
5118N
Voice switched hands free intercom with buttons to control “answer/end conversation”, “door open”,
“privacy on/off” and “service” button. In addition there are 4 LED’s to indicate the status of “answer/end
conversation”, “door open/closed”, “privacy on/off” and auxiliary “service” status. Call tone and loud-
speaker volume controls are also incorporated on this model.
Art.
HANDS FREE INTERCOMS FOR VX2200 DIGITAL SYSTEM
5178N
Voice switched hands free intercom with buttons to control “answer/end conversation/recall/simplex
conversation”, “door open”, “privacy on/off” (programmable duration) and “service” button. In addition
there are 4 LED’s* to indicate the status of “answer/end conversation”, “door open/closed”, “privacy on/
off” and auxiliary “service” status. Call tone and loudspeaker volume controls, through assigned but-
tons, are also incorporated on this model. It is possible to program the melody (9 available), the num-
ber of rings (max 9) and the privacy service duration (max 20 hours). Surface wall mount installation.
VR5178
Same features of Art. 5178 but vandal resistant version: the“service”button that is missing, is replaced by
the“privacy”button that works also as a“service”button. Adjustments and programmable functions are
the same but are carried out in a different way. This version is available flush mount only and included a
2.5mm brushed stainless steel face plate and flush box with security screws (no mounting plate required).
Art.
HANDS FREE INTERCOMS FOR VX2300 DIGITAL SYSTEM
5188N
Voice switched hands free intercomwith buttons to control“answer/end conversation/recall/simplex con-
versation”,“door open/intercommunicating call”,“privacy on/off”(programmable duration) and“BUS relay
control”(Art. 2305) button. In addition there are 4 LED’s* to indicate the status of“answer/end conversation”,
“door open/closed”,“privacy on/off”and programming status. Call tone and loudspeaker volume controls,
through assigned buttons, are also incorporated on this model. In addition to programming required from
the VX2300 digital system (address, extension address and intercommunicationmode) it is possible to pro-
gram the melody, the number of rings and the privacy service duration. Surface wall mount installation.
* The operation of some LED’s and the functions described may require additional cabling
Vandal Resistant line
5000 Series Eclipse range
Hands Free Intercoms
