Art. VR5478
35
GENERAL CATALOGUE
Art.
HANDS FREE VIDEOMONITORS FOR VX2200 DIGITAL
SYSTEMUSING COAX OR BALANCED VIDEO SIGNAL
VR5478
Intelligent Hands free videomonitor using 3.5”full colour active matrix LCD OSDmonitor for VX2200 digital
video door entry systems using composite (coax cable) or balanced (twisted pair) video signal.
Equipped with a vandal proof 2.5 mm stainless steel plate.
Including 3 buttons“door-open/concierge-call”,“answer/camera recall/’push to talk”,“privacy/call reject/ser-
vice”plus 3 LED’s* for visual indication of all functions. Adjustments & programmable options (through OSD
menu): loudspeaker volume, call tone volume, picture contrast, brightness and hue, privacy duration, call
tone melody, number of rings. Address and videomode are programmable through 2 dip-switch banks. Also
includes a local bell function.
* The operation of some LED’s and the functions described may require additional cabling
Vandal Resistant line
5000 SERIES VIDEOMONITORS WITHMEMORY BOARD
As the 3000 Series, memory board facility is also avaible on the 5000 Series (except Art. VR5478).
Video monitors having a memory board can record up to 512 pictures (from the camera video) showing the date
and time of recording.
Recording canbeboth automatically (by pressing the correspondingpushbutton and indicatedby its LED) andmanually.
In the first case the videophone stores a frame when a call is made (so while the user is away, fromhome he can have
a record of the visitors who’s called with the date and time of the visit).
Manual recording, instead, allows to record a frame at each button pression.
When all memory locations are full, the oldest record will be overwritten (First in first out). When the memory board
is required in 5000 Series video monitors (Art. SL5418N, SL5456, SL5478N and SL5488N) , S1, S2 and
buttons are
no longer used as service buttons, but they are used for the memory board.
In these videomonitors , date, brightness, contrast and hue settings can be done throughOSDmenu (On ScreenDisplay).
To order video monitors with memory board facility (for those models where it is available), suffix “/MV” to the
product code.
5000 Series Eclipse range
Hands Free Video Monitors
