Art. KRV78/B
Art. KRV88/B
Art. KRV98/B
Art. KRV76/W
Art. KRV86/W
Art. KRV96/W
52
GENERAL CATALOGUE
Kristallo Series
3.5”Videophones
Art.
3.5” VIDEOPHONES FOR VX2200 DIGITAL SYSTEM
KRV78
Flush mount hands free video monitor using 3.5” full colour active matrix LCD display with OSD (On
Screen Display) for video door entry systems using composite (coax cable) or balanced (twisted pair)
video signal. All buttons use capacitive touch sensor technology, 3 of these buttons have multiple
direct functions such as “door-open/concierge-call”, “answer/camera recall/simplex conversation” and
“privacy/call reject/service/programming and adjustment menu access”).
3 LED’s give visual indication of operations while the other 5 buttons allow navigation of the programming
menu’s.
Programmable options: loudspeaker volume, call tone volume, picture contrast, brightness and hue, privacy
duration, call tone melody, number of rings, address and videomode. Also includes a local bell function.
Available in black (add to the product code “/B”) or white (add to the product code “/W”) finishes.
KRV76
As Art. KRV78 but surface mounting version with handset for conventional use in addition to the hands free mode.
Art.
3.5” VIDEOPHONES FOR VIDEX “2 WIRE BUS” VIDEOKITS AND VX2300 DIGITAL SYSTEMS
KRV88
Flushmount intelligent Hands free videomonitor for the VX2300 digital systemusing 3.5”OSD full colour
active matrix LCDmonitor, with touch sensitive buttons for“door open / service”,“answer/camera recall”,
“privacy/bus relay”plus 5 navigationmenu buttons and 3 LED’s related to the videophone operation.
Additional features include a real time clock, a temperature sensor and a serial RS232 port for future
integration with home automation systems.
KRV86
As Art. KRV88 but surface mounting version with handset for conventional use in addition to the hands free mode.
