Art. 8851
Art. 8852
Art. 8853
Art. 8852/A
Art. 8872/A
Art. 8881/BL
394
274
154
144
263
382
115
52
144
115
30
30
30
30
115
52
115
52
62
GENERAL CATALOGUE
FRONT SUPPORTS, RAINSHIELDS, SURFACE MOUNTING UNITS
The 8000 Series modules are available in both flush and surface mounting units. The flush mounting units com-
bine with rain shields to cover any cutouts in the wall. Surface mounting units, flush mounting units and rain
shields are available in the following finishes.
A
Aluminium.
BL
Black.
When ordering, suffix the product code with /A for aluminium or /BL for black.
FRONT SUPPORT
For flushmountedmodules complete with stainless steel hinge and back box. width 115 mm., recessed depth 30 mm.
Art.
MODULES FRONT FRAME (mm)
BACK BOX (mm)
8851
1
115x154x22
109x144x30
8852
2
115x274x22
109x265x30
8853
3
115x394x22
109x385x30
8000 Series
Modular System
