Art. 8800
Art. 8900
Art. 8849
Art. 8830
61
GENERAL CATALOGUE
ACCESS CONTROL MODULES
Videx produce a wide range of digital codelocks for “access control” systems among which there is a modular
version of the 8800 and 8900. The codelocks use the latest microprocessor based PCB, which (when combined
behind its tough stainless steel keypad) gives trouble free controlled access. The unit is easy to install and
extremely robust at a low cost. It can be used as a stand alone keypad or combined with other 8000 Series audio
and video modules.
Art.
CODELOCKS MODULES
8800
Codelock module, 2 codes/2 relay outputs.
8900
Codelock module, 100 codes/2 relay outputs.
Art.
“READER” MODULES FOR CODED KEYS
8849
Videx proximity coded-key readers are available in a 8000 Series module.
The device includes the reader circuit (with a reading range between 20 and 50mmdepending on the key
type used). A tri state LED and Buzzer is an intricate feature to indicate if a key has been accepted or denied.
Connectionbetween the“VproX”reader and theControl Unit requires aminimumof 5wiresover amaximumdis-
tanceof 200mts.This unit combines apolycarbonate readerwindowwith a stainless steel or aluminiumframe.
CAMERA MODULES
The camera module from 8000 Series is the Art. 8830. The module have a build in adjustable (13 degree in any di-
rection) CCD camera with infrared illumination LED’s, include the anti-mist system (requires an additional 13Vac/
dc power source) and may be set for video composite signal (coax cable) or for the balanced one (twisted pair
wire) according to the system requirements.
It can be used in traditional, “4+1” (combined with Art. 8835), VX2000 and VX2200 video door entry systems.
The camera is colour Day/Night.
Required power supply 12/24 Vdc.
8000 Series
Modular System
Art.
CAMERA MODULES FOR TRADITIONAL, 4+1 , VX2000 AND VX2200
VIDEO DOOR ENTRY SYSTEMS
8830/C
Day/night colour camera module.
