Kristallo Series
3.5”Videophones
Automatic pictures capture enabled
Automatic videoclips capture enabled
Stored pictures scrolling
Stored videoclips scrolling
KRISTALLO VIDEOPHONES WITHMEMORY BOARD
Videx is always looking to enhance the security level of its sys-
tems. For this reason Videx have added optional video memo-
ry functions to the KRISTALLO videophones range.
Videophones with memory board facility can store up to 128
still pictures and up to 66 video clips (15 seconds duration
without audio). The images/videos are date and time stamped.
It is also possible to copy these images to a microSD card (from
1 to 16Gb), allowing the pictures and videos to be viewed on a
PC or any other device able to read the microSD card.
The picture or video clip storage can be triggered automati-
cally or manually: when in automatic mode the videophone
stores a picture or a 15 seconds video clip upon receiving a
call (this enables the user, whilst away from home, to record
visitors who have called, the date and time stamp allows
you to see the time of the call). For manual storage the vide-
ophone stores a picture or a 15 seconds video clip by pressing
the manual store button. Kristallo videophones with memory
board have two additional OSD (On screen display) menus, one to manage the operation and the other to
manage and scroll through the stored pictures and videos.
The operationmenu (always available when the videophone is switched on) offers: the option to store a picture
or a video clip, to enable or disable automatic storing, to manual store and to enter into picture/video scroll-
ing. The picture/video scrolling menu offers: the option to select pictures or videos, to scroll pictures or videos,
to delete one or more pictures/videos and to copy the current viewed picture/video on to the microSD card.
When the internal memory of up to 128 pictures or 66 video clips is full, the next picture/video clip will delete the
oldest (First-In-First-Out).
To order videophones withmemory board facility (for thosemodels where it is available), suffix“/MV”to the product
code.
Art.
3.5” VIDEOPHONES FOR IP SYSTEM
KRV98
Kristallo design flush mount hands free IP videophone using a 3.5” LCD TFT High Definition display for
IP based video door entry systems. All buttons use capacitive touch sensor technology, 3 of these but-
tons have direct functions such as “door-open”, “answer/camera recall” and “privacy”. 3 LED’s give visual
indication of operations while the other 5 buttons allow to surf the programming menus. A built in
web server allows to set operation parameters and firmware update . Compatible with the SIP proto-
col, it can be connected with VOIP switchboard systems and as for VIDEX systems a self search/setting
function is available for the Videx IP devices connected on the same network.
The unit can intercommunicate with other devices of the system (outdoor stations, videophones, tablet
or PC with client installed) selecting the user to be contacted through a complete contacts’list or through
“favorite”list (communication with outdoor stations is audio/video and it’s possible to activate the relays);
The videophone has an integrated picture memory facility with automatic or manual capture and the
stored pictures can be viewed from the built-in history of events.
The Privacy function has a programmable activation time from 30 min to 24 h or unlimited, the melody
and desktop can be customized by loading audio files and pictures and having an internet connection
on the same network you also use the “Weather Forecast” function through the google weather service.
A specific menu option allows to select and activate the relays of the outdoor stations without being
called previously.
The Ethernet interface is a 10/100 Mbit and the required power supply is a 12Vdc 1A PSU or nothing
when the videophone is connected to a PoE router or switch.
KRV96
As Art. KRV98 but surface mounting version with handset for conventional use in addition to the hands free mode.
