Art. 4828C
128
GENERAL CATALOGUE
Art.
ACCESSORIES FOR FINGERPRINT READERS
4828C
Desk mounted capacitive finger print reader housed in
a white ABS plastic case 110 x 70 x 30mm.
Normally used in combination with PC software for registration of
finger prints to be uploaded to the reader.
Art.
POWER SUPPLIES
321
230/13Vac 15VA transformer, with internal PTC overload protection.
PSU110
Power Supply 13V DC 1Amp, battery backup facility (12V-2A). Fuse for overload protection.
Rack version unboxed, dimension: 175x65x60mm.
Art.
DB9 SOCKET EPROMMEMORIES
416
“Socket Eeprom Memory”, 16Kbyte for “VproX-250” system. Plastic socket standard DB9, grey colour.
417
“Socket Eeprom Memory”, 64Kbyte for “VproX-1000” system.
Plastic socket standard DB9, grey colour.
418
“Socket Eeprom Memory”, 256Kbyte for “VproX-4000” system.
Plastic socket standard DB9, grey colour.
Art.
DB9 SOCKET EPROMMEMORIES PROGRAMMER
420
“Socket Eeprom Memory” programmer unit to manage the copy/erase of the data present in the
“VproX” access control. The device has 2 connectors where the 2 “Socket Eeprom Memory ” (source
and target) must be plugged in order to copy or erase the “VproX” system data. The device is available
in a plastic box (110x70x30mm) and power required is 8÷15Vdc or 9 volt battery.
Art.
MINI PARALLEL PRINTER
450
Unboxed 24 column mini printer plus winder unit, rack mounting.
Parallel interface (compatible with “VproX” system), power required: 5V DC 1,5Amp. max.
Art.
PC-KEYSTORE INTERFACE MODULE
430N
“PC-Keystore Interface Module” to manage the “VproX” systems data directly from the PC, by using
a simple electronic device (9V battery powered or 8÷15Vdc power supply). The interface uses the
2“Socket Eeprom Memory” of the “VproX” system thathave to be plugged into the 2 connectors on
the device. Through the special program“VP4000” (provided on CD-ROM) and RS232 cable (provided)
it is possible to manage all data of “VproX” system. At the end, the 2 “Socket Eeprom Memory”must
be reconnected to the VproX” system.
The device is available in a plastic box (150x70x40).
Accessories
