Art. 512A
Art. 512E
Art. 512D
Art. 506N
Art. 510N
126
GENERAL CATALOGUE
Accessories
Art.
ENSLAVEMENT RELAYS
506N
Enslavement Relay (230Vac 5Amax) enables the control of stair lights or other
power peripheral. In a standard 5 modules A type Dim Box (87.50 mm).
506T
Enslavement Relay as above but timed 2 - 100Sec.
512DR
Extension Relay for VX2200 powered by the “2 Wire BUS”. Relay contact 1A
125Vac Max. In white ABS plastic box 110x70x30 mm.
Art.
ADDITIONAL SPEAKERS
512A
Additional speaker 45 Ohms 0.5W built into an ABS plastic case. It can be used with positive signal (gen-
erated by Art. 507N- 509N-510N) or negative signal generated by Art. 835M-0/..-1..- 2/..
In white ABS plastic box 110x70x30 mm.
512E
Extension Sounder as above but incorporating a modulated tone generator. Powered by 10/15V AC can
also be used in parallel with a standard 12V AC buzzer. In white ABS plastic box 110x70x30 mm.
512D
Extension Sounder for digital system VX2200. Is connected directly to the “2 Wire Bus”.
In white ABS plastic box 110x70x30 mm.
Art.
MODULATED TONE GENERATORS
507
Modulated Tone Generator in a standard 5 modules A type DIN box (87.5 mm).
3807
Modulated Tone Generator specific for “1+1” audio entry systems and “4+1” video entry systems. In a
standard 3 modules A type DIN box (52,5 mm).
509N
Speech Cut Off Device + tone generator for use on 4+ 1 systems with privacy of speech and lock re-
lease (one required per system). It enables speech and operation of lock to be carried out only from the
last telephone called. In a standard 5 modules A type DIN box (87,5 mm).
510N
Switching relay plus modulated tone generator for intercommunicating systems using 928 or 3117
telephones. It allows a private conversation between extensions and outdoor station. It also incorpo-
rates a relay to operate the lock. In a standard 5 modules A type DIN box (87,5 mm).
Art.
EXTERNAL CCD CAMERAS
989
External colour CCD Camera complete with white light illumination LED’s, weather-proof housing and
mounting bracket. Power supply 12 Vdc, coax video signal output.
