Art. VproX - 4000DM
VP4000-VproX-1000/4000 Win Software
118
GENERAL CATALOGUE
VproX-4000/DM
Door monitoring unit compatible with the VproX-4000 system. This device enables the moni-
toring of doors for either being open or closed. Four doors can be monitored by each unit.
The information will be relayed to the VproX-4000 controller and from there on to the PC. The
PC can then monitor the length of time a door is open and if necessary activate an alarm. This
greatly improves the security level of the VproX-4000 system. It is possible to connect up to 5
door monitoring units in parallel (To control up to 20 doors max.) on the same serial BUS used
by VproX- 1000/A sub units (Three wire bus).
Available in a plastic, standard 5 module A type DIN box with 12Vdc 1VA max.
Art.
MANAGEMENT SOFTWARE FOR VPROX CONTROL UNITS
VP4000
VproX-1000/4000 Win Software - Special program for the Windows® environment to manage the
“VproX-1000” and the VproX- 4000 controller units via a PC. The program incorporates user friendly
menus with on line “help”. When a database is created it is possible to associate the “user name” to each
key stored in the memory and to have access to all configuration parameters. The software allows for
the deletion or addition of keys and operates many other useful functions. It is also possible to down-
load from the “VproX system the “event report”memory and to list its contents by name, key number or
chronological date. If the PC program remains connected “on line”, the screen will show the data of the
last 5 entries with the photo ID of last user.
The program is supplied on CD-ROM with a RS232 cable.
When used with the VproX-4000, the software has the following additional features:
- Door monitoring when using the VproX-4000/DM module.
- Make a note of a particular key so that you can be informed when it is next used.
- Assign credits to keys so that when all credits are used the key is disabled.
A different number of credits can be assigned to different doors.
- Program keys that will only operate once or that will expiry after a certain date.
- Reset the time and date on the VproX-4000 CPU to match the PC time and date.
Access Control
