RS-485 BUS CONTROL UNITS PC PROGRAMMING SOFTWARE
Two versions of RS-485 software are available.
The first provided with kits Art. 4827 and Art. 1057 allows programming of the Art. 4821, 4823 and 4823C finger
print readers when directly connected to the PC using Art. 4827 or when linked to the BUS of the VX1050 using
Art. 1057. The software also provides a log function when connected to the Art. 4823 or through VX1050.
The second version provided with kit Art. 1058 allows the programming of control unit VX1052 and gives real time
monitoring of all activities when connected to a PC.
Art.
DESCRIPTION
4827
RS-232 connection cable with Windows® programming software for Art. 4821C and 4823C. This software
allows data to be stored in a PC file and in the memory of the finger print reader module. The name of
each user can be stored on the PC and the same information as a numeric ID in the reader memory. One
or more finger prints can be stored for each user and each finger print can be assigned to one of the 3 on
board relays, each relay can be programmed individually with its own operating time. When the software
(Art. 4827) is used with reader Art. 4823C, events log reading is available. The software kit can also be
used with Art. 4828C (see accessories section) desk mount finger print reader.
1057
As Art. 4827 with a PC / RS-232 connection cable for use with VX1050 control unit. The software allows for
all the above functions of the Art. 4827, when the finger print readers are linked to the RS-485 BUS of the
VX1050 control unit.
1058
PC / RS-232 connection cable with Windows® programming software for use with VX1052 control unit.
The software allows data to be stored in a PC file and in the memory of the VX1052.
The software provides for the storing of up to 3000 users. Each user can have the following:- a user ID set-
ting for each user, the users name, authorisation expiry date (if enabled), credits (if enabled), time zones,
assignments to which doors can be accessed and additional information including photo ID, telephone
numbers and e-mail address. The software also allows for the setting of time zones, door status monitor-
ing (real time), event log of the last 7000 events, the setting of the individual opening time for each door
connected to the system and the number of credits assigned to an individual or group of users.
