Art. VproX - 1000/4000
Art. VproX - 1000A
117
GENERAL CATALOGUE
VproX-1000
Control unit for 4 main doors (Expanding up to 20), and up to 99 apartment doors (by adding the
VproX-1000A unit for each door that requires to be controlled) and 1000 proximity keys. 2 x 16
chars LCD display and 4 x 4 keypad to gain access (by use of a “master code”) for the programming,
deleting and testing of a single key, to set the door opening times (from 1 to 255secs) and the 4
“time bands” (keys working time). Internal memory for the “event report” (up to 512), and a serial
RS232 port for connection to a P.C. with special Videx software. Alarm relay with timed activation
after 5 attempts of entering a “not allowed” key. Real time /clock on board (with backup battery)
and 2 removable “Socket Memory Eeprom” for the “main memory” and “back up memory”where all
system data is contained. Power required: 12Vdc 4VA max.
VproX-4000
Includes all the functions of VproX-1000, plus the followings additional features:
- Memory capability up to 4000 keys
- Internal memory for the ‘Event Report’ now stores up to 2048 events
- ‘Direct copy’ function to copy the ‘Main’memory module onto ‘Backup’memory module
- Control of ‘VproX-4000/DM’ door monitoring device, to monitor the door status from the PC
- Fully compatible with the advanced PC software ‘VP4000’.
Art.
VPROX SYSTEM EXPANSION DEVICES
VproX-1000A
Remote control unit for “VproX” proximity reader compatible with “VproX-1000/4000” system. This
device allows for the further expansion to the 4 main doors included on the “VproX- 1000/4000”
unit up to 20 (by adding one unit for each door) or to control the secondary apartment doors up
to 100 (by adding one unit for each door). By using a minimum 3 core cable all the remote control
units are connected in parallel on a serial BUS to the “VproX-1000/4000” control unit.
Available in a plastic, standard 9 module A type DIN box (157.50mm) with 230Vac 20VA max
power supply with the facility to connect a 12V – 2A backup battery.
Access Control
