Art. 3980
Art. 3931
20
GENERAL CATALOGUE
VIDEOPHONE WITHMEMORY BOARD
Videx is always looking to enhance the security level of its
systems. For this reason Videx have added optional video
memory functions to its already extensive range of videophones.
Videophones with memory board facility can store up to 128
video frames with relevant date and time stamp. The storage
can be triggered automatically or manually: when in automatic
mode (activated by pressing the relevant push button and
indicated by a LED) the videophone stores a still frame on each
external call (this enables the user, whilst away from home, to
have a record of the visitors who have called all with a date and
time stamp).
For manual storage the videophone stores a still frame by
pressing the relevant push button. In addition to the normal 5
push buttons, these videophones include a further 6 small push
buttons for controlling the memory board. They enable: viewing
of stored images; deleting stored images or to alter memory
board date and time. When the 127 memory locations are full,
the next frame will shift the stored frames of one position toward
the bottom of the memory deleting the frame in position 1 and
will over write the frame in position 127 (First-In-First-Out).
To order colour videophones with memory board facility
(for those models where it is available), suffix “/MV” to the
product code.
The memory board facility is not available on Art. 3481.
Art.
ACCESSORY 3000 SERIES VideophoneS
3931
Table top desk kit for 3000 Series videophones.
Dimensions: 182 X 76 X 190 mm.
3980
Wall mounting plate plus pcb connection board for 3000 Series videophones.
One required for each videophone.
3000 Series
Videophones
