Art. 3618
Art. 3656
Art. 3676
Art. 3678
Art. 3686
Art. 3612
Art. 3631
24
GENERAL CATALOGUE
3618
“High End”Videophone (with hands free facility) using 3.5”full colour active matrix LCDmonitor for tradi-
tional video door entry systems using either composite (coax cable) or balanced (twisted pair) video signal.
Including 3 buttons (“door open”, “answer/camera recall/’push to talk’” & “privacy/call reject/service”)
plus 3 LED’s* for visual indication of all functions. Adjustments & programmable options (through OSD
menu): loudspeaker volume, call tone volume, picture contrast, brightness and hue, privacy duration,
call tone melody, number of rings, door open time and video mode. Also includes a local door bell
function. The Art. 3618 is surface mount and requires the Art. 5980 connection board and wall mount-
ing plate. It can be used as an alternative to the Art. 3411, 3412, 3612, 5418, SL5418N and 5412.
Please note: this model requires an additional wire for 12Vdc supply and cannot be connected in paral-
lel with the other 3000 Series models mentioned above within the same apartment.
Art.
VIDEOPHONESFORTRADITIONALVIDEODOORENTRYSYSTEMSUSINGCOAXORBALANCEDVIDEO
3612
Videophone using 3.5” full colour active matrix LCD OSD monitor for traditional video door entry sys-
tems using either composite (coax cable) or balanced (twisted pair) video signal. Including 3 buttons
(“Door Open”, “Camera Recall” & “Service”) plus 3 LED’s for visual indication of all functions. Controls for
call tone volume (3 position: Privacy/mute call, medium and high), picture brightness and hue. Also
includes a local bell function. The Art. 3612 is surface mount and requires the Art. 5980 (connection
board plus wall mounting plate).
It can be used as an alternative to the Art. 3411, 3412, 3618, 5418, SL5418N and 5412.
3600 Series
Videophones
Art.
VIDEOPHONES FOR “4+1” VIDEO DOOR ENTRY SYSTEM (NO COAX)
3631
3.5’’ LCD TFT colour monitor, with “auto-recall”, “door open” and “service/auto-recall” buttons (the “servi-
ce/auto-recall” button can be set either a “service” or “auto-recall” button).
3 LED’s* indicating: star-up (dot button), door open (key button and it requires a specific connection),
privacy (two dots key and it requires a specific connection).
Adjustments: melody volume (2 levels plus privacy position), hue and brightness.
