GENERAL CATALOGUE
3600 SERIES LOW COST HIGH SPEC COLOUR VIDEOPHONE
Based on the popular 3000 Series of videophones the 3600 videophone is both elegant
and robust, manufactured in white impact resistant ABS plastic and incorporating the latest
technology and voice switching techniques these models allow the user greater choice for their
chosen settings and operation compared to the previous 3000 Series.
Models are available in two lines: the “Standard” and the “High End”.
The“Standard”line shares many features with the 3000 Series colour videophones having similar
or improved functionality but with the benefit of reducing the prices in line with the 3000 Series
black & white videophones.
The “High End” line offers the same functions as the “Standard” line but with the addition of
hands free speech (push to talk ‘simplex’ function also available) and OSD (On Screen Display)
which offers greater functionality and flexibility to the user through on screen information,
programming menu’s and adjustment menu’s.
The 3600 Series Videophones use a high quality 3.5” colour LCD TFT display (including OSD in
the “High End” range) and house 3 large buttons on the front to manage the system operation,
depending on the model these buttons are also used for programming and adjustments. Each
button has an associated LED (Additional connections may be required).
Also standard to the 3600 videophone is a local door bell input.
Programming and adjustment options can include (depending on the model): privacy time, call
melody, number of rings, call tone volume, speech volume, picture brightness, contrast and hue.
All 3600 Series videophones require awall mounting connectionplateArt. 5980 (sold separately).
Ideal for first fixing installations the wall plate includes all terminations. The videophone then
simply plugs onto the plate and clips into position.
With the exception of the VX2300 and video kit models, all 3600 Series videophones will accept
both composite video signals (coax cable) and balanced video signal (2 wire twisted pair).
3600 Series
Videophones
3600 Series videophone
Surface mount only
