GENERAL CATALOGUE
5000 Series Eclipse range
Hands Free Intercoms & Video Monitors
The
5000 Series
range of hands free (simplex or voice switched depending upon model) audio
and video monitors can be identified by their slim and compact design, allowing the 5000 Series
units to be used in areas where space is limited.
The hands free voice switching technology delivers excellent audio quality and efficient noise
cancellation (larsen effect). The choice of manufacturing technology has resulted in the slim and
compact design.
The Eclipse range has “answer/recall”, “door open” and “privacy on-off” (which are user
programmable) buttons common to all products (except Art. 5112 where the privacy service is
activated by a switch), service push buttons will vary from model to model (audio intercom or
video monitor) but will have a minimum of one. LED’s are also provided to give visual indication
of functions and system operation.
All Eclipse audio and video units are supplied surface mounting as standard. A flush mounting
kit is also available for the Eclipse video monitor.
The installation of the surface or flush audio or video monitors is carried out by attaching the flat
ribbon cable on the front panel to the pcb connector board which is housed in the wall fixing
plate (the wall fixing plate is the intercom/videophone back cover) once all cables have been
terminated into the pcb connector board the ribbon cable can be connected and the front plate
can then be securely clipped onto the wall fixing plate.
The Eclipse video monitor is only available with a colour 3.5” active matrix LCD display. Standard
controls include call tone volume (some versions include a choice of call tone melody), speech
loudspeaker volume and image brightness and hue controls.
In addition to the standard polar white finish, the Eclipse range of audio and video monitors in
surface, flush and including optional handset kits are available in two additional colours.
--
Carbon Fibre effect (add “/CA” to the product code when ordering).
--
Silver (add “/CR” to the product code when ordering).
VIDEX has further expanded the 5000 Series eclipse range to include intercoms and
videophones for “4+1” audio door entry systems or traditional video door entry systems using
composite video signal (coax cable) or balanced (twisted pair) and for VX2200 (“2 Wire BUS”
audio, “6 Wire Bus” video) and VX2300 (“2 Wire BUS” video) digital systems.
For harsher environmental applications, to complete the range, Videx have introduced a Vandal
Resistant hands free video monitor (Art. VR5478) and a Vandal Resistant hands free intercom
(Art. VR5178) both for use on the popular VX2200 digital system. These units are manufactured
with brushed 2.5mm stainless steel face plate and are designed for flush mounting only.
The functions and controls as indicated above may vary and will depend on the system used.
