Art. 4202
Art. 4302N
Art. 4202R
Art. 4302NR
Art. 4202V
Art. 4302NV
Art. 4202RV
Art. 4302NRV
Optional
71
GENERAL CATALOGUE
Art.
DIGITAL CALL PANELS FOR VX2200 DIGITAL SYSTEMS (2 WIRE BUS AUDIO, 6 VIDEO)
4202
In addition to the speaker unit functions, the panel includes a 2x16 Characters LCD display with blue
back light , the illumination LED’s for the keypad plus a keypad with 18 buttons of which 10 are nu-
meric buttons (0..9), “ENTER” and “CLEAR” buttons plus 6 alpha buttons (A..F).
The panel has the speech board facility (optional chip installation) to supply audio messages in
addition to written messages provided from the display.
4202V
As the 4202 plus a built-in CCD camera with IR illumination LED’s. For the panel there are 2 models
available with the following camera options: colour Day/Night or colour Day/Night with Wide Angle
camera.
In the first model the built-in camera has horizontal & vertical adjustment of 10 degrees while with the
Wide Angle the camera is fixed but the field of view is 170 degrees.
The camera can be set to work with composite video signal (coax cable) or balanced video signal (one
twisted pair).
To order the Wide Angle camera add “/wide” to the code.
4000 SERIES DIGITAL CALL PANELS FOR VIDEX DIGITAL SYSTEMS
These panels are compatible with the 4000 Series modular system and in each version (audio or audio/video) they
have the size of two 4000 Series modules. The front panel finishes are the same as for the 4000 Series Modules.
Complementing all digital door panels manufactured by Videx is the ability for all users to have their own unique
access code. The access code can have up to six digits and is blind to onlookers.
4000 Series
Modular System
