66 GENERAL CATALOGUE
The 4000 Series is a advanced range of
modular door panels.
The 4000 Series has been designed using
the latest 3D modelling software. The de-
sign is characterised by a number of unique
features: the modules with front plate and
push button are manufactured in mir-
ror finish stainless steel, the frame (which
is also the module support) is manufac-
tured from one piece of die-cast alumini-
um alloy which gives substantial strength
to the outdoor station, modules are
attached to the module support frame us-
ing a simple but strong clip system (vandal
resistant modules are secured to the front
support frame using studs and fixing rails),
the fixing system of the front panel to the
back box (flush or surface) uses torx pin ma-
chine screws.
The modular system consists of 3 main
items:
--The modules
(standard and vandal resistant line).
--The front supports
(for flush mounting).
--The surface mounting units
(for surface mounting).
The module support frame (flush or surface)
is hinged to the back box. This allows for
ease of cable installation and connection as
both hands are free.
The standard finish for the module support
frames and surface back boxes is embossed
metallized “gunmetal grey” while the mod-
ule front plates are in mirror finish stainless
steel for the standard line and brushed fin-
ish stainless steel for vandal resistant line.
The module support frames are also available
in two other finishes: high brass PVD (gold
chromium effect) and Sky chrome PVD (silver
chromiumeffect).
The module front plates (for the standard
line only) are also offered in anodized alu-
minium and high brass PVD.
4000 Series
Modular System
4000 Series standard range modules
Modules available materials and finishes 67
“Speaker unit” front panel modules 68
Digital call panels for
Videx digital systems 71
Speaker unit front panel modules with
built-in camera for traditional video door
entry systems using coax cable or balanced
video signal (non “4+1”) 73
Camera modules 73
Blank and information modules 74
Button expansion modules
(single and double row) 74
Access control modules 75
4000 Series GSM range modules
GSM speaker unit front panel modules 76
For GSM intercom up to 10 button
audio system 76
For GSM intercom up to 50 button
audio system 77
For GSM intercom up to 255 calls audio system 77
4000 Series vandal resistant range modules
Speaker unit modules 81
Vandal resistant modules 81
Camera modules 82
Button expansion modules 83
Modules for access control systems 83
Digital call panels for
Videx digital systems 84
Front support and surface mounting unit
Front support 86
Front support and surface mounting unit
available materials and finishes 86
Surface mounting unit 87
Antitampering 87
4000 Series IP range modules
IP system 78
