Art. 4202
Art. 4302N
Art. 4202R
Art. 4302NR
Art. 4202V
Art. 4302NV
Art. 4202RV
Art. 4302NRV
Optional
72
GENERAL CATALOGUE
Art.
DIGITAL CALL PANELS FOR VX2200 DIGITAL SYSTEMS (2 WIRE BUS AUDIO, 6 VIDEO)
4202R
In addition to the speaker unit functions, the panel includes a 2x16 Characters LCD display with blue
back light , the illumination LED’s for the keypad plus a keypad with 15 buttons of which 3 are used for
the repertory name, 10 are numeric buttons (0..9) plus “ENTER” and “CLEAR” buttons.
The panel has the speech board facility (optional chip installation) to supply audio messages in addi-
tion to written messages provided from the display.
4202RV
As the 4202R plus a built-in CCD camera with IR illumination LED’s. For the panel there are 2 models avail-
able with the following camera options: colour Day/Night or colour Day/Night withWide Angle camera.
In the first model the built-in camera has horizontal & vertical adjustment of 10 degrees while with the
Wide Angle the camera is fixed but the field of view is 170 degrees.The camera can be set to work with
composite video signal (coax cable) or balanced video signal (one twisted pair).
To order the Wide Angle camera add “/wide” to the code.
Art.
DIGITAL CALL PANELS FOR VX2300 DIGITAL SYSTEMS (2 WIRE BUS)
4302NV
In addition to the speaker unit functions, the panel includes a high quality CCD camera with IR illumi-
nation LED’s, a 2x16 Characters LCD display with blue back light , the illumination LED’s for the keypad
plus a keypad with 18 buttons of which 10 are numeric buttons (0..9), “ENTER” and “CLEAR” buttons
plus 6 alpha buttons (A..F). The panel has the speech board facility (optional chip installation) to supply
audio messages in addition to written messages provided from the display. For the panel there are 2
models available with the following camera options: colour Day/Night or colour Day/Night with Wide
Angle camera. In the first model the built-in camera has horizontal & vertical adjustment of 10 degrees
while with the Wide Angle the camera is fixed but the field of view is 170 degrees.
The module is available also in audio version Art. 4302N.
4302NRV
In addition to the speaker unit functions, the panel includes a high quality CCD camera with IR illumina-
tion LED’s, a 2x16 Characters LCD display with blue back light , the illumination LED’s for the keypad plus
a keypad with 15 buttons of which 3 are used for the repertory name, 10 are numeric buttons (0..9) plus
“ENTER”and“CLEAR”buttons. The panel has the speech board facility (optional chip installation) to supply
audio messages in addition to written messages provided from the display.
For the panel there are 2 models available with the following camera options: colour Day/Night or colour
Day/Night withWide Angle camera. In the first model the built-in camera has horizontal & vertical adjust-
ment of 10 degrees while with theWide Angle the camera is fixed but the field of view is 170 degrees.The
module is available also in audio version Art. 4302NR.
To order the Wide Angle camera add “/wide” to the code.
4000 Series
Modular System
