Art. 4849
Art. 4850
Art. 4850/P
Art. 4821C
Art. 4823C
Art. 4800
Art. 4801
Art. 4900
75
GENERAL CATALOGUE
Art.
CODE LOCK MODULES
All the 4000 Series codelock modules can operate in stand-alone mode. The new Art. 4801 module can also work in
network mode when linked by a serial RS-485 BUS to a remote control unit (VX1050, VX1052). The programming of
the modules can be carried out through the module keypad or, for the Art. 4801, through a pc software (Art. 4829
CD programming software plus connection cable).
4800
Codelock module, 3 codes / 3 Relays.
4801
Codelock module, up to 3000 codes / 2 Relays.
4900
Codelock module, 100 codes / 3 Relays.
Art.
PROXIMITY KEY READER MODULES
The 4000 Series of proximity modules has been expanded to include two new stand alone units: Art. 4850
and Art. 4850/P. Both models can be programmed manually or the Art. 4850P via an RS-232 serial connection to a
PC (Art. 4829 CD programming software plus connection cable).
The 4850 will control up to 100 keys (fobs) while the 4850/P up to 1000 keys (fobs) and can be networked
when linked by a serial RS-485 Bus to a remote control unit (VX1050, VX1052). The Art. 4849 reader module requires
one of the following control units to operate (VproX20, 100, 250, 1,000, or 4,000).
4849
Proximity key reader module.
4850
Proximity key reader module, 1 relay, 100 keys.
4850/P
Proximity key reader module, 1 relay, 1000 keys.
4829
CD Programming software plus connection cable for VIDEX modules Art. 4850/P and Art. 4801. The
software allows to program the users in the unit memory. With the PC connected and the software run-
ning, it allows also to have an events LOG.
Art.
FINGERPRINT READER MODULES
To compliment and expand the range of access control modules for the 4000 Series. Videx have introduced two
Fingerprint readers modules Art. 4821C (1000 fingerprints) and Art. 4823C (3,000 fingerprints). Programming of
both versions can be carried out using the on board switches situated on the rear of the units or by a PC via a serial
RS-232 connection. The Art. 4821C and Art. 4823C are able to work as stand-alone units or networked, using remote
control units (VX1050 or VX1052) via an RS-485 serial Bus.
4821C
Fingerprint reader capacitive sensor, 3 relays, 1000 fingerprints.
4823C
As Art. 4821C but up to 3.000 fingerprints.
ACCESS CONTROL MODULES
VIDEX produce access control systems that can work stand-alone or can be incorporated with audio or video door
entry systems. For more details about access control systems see the relevant section of this catalogue.
4000 Series
Modular System
