Art. VR4KCMC
Art. VR4KCMCW
Optional
82
GENERAL CATALOGUE
The VR4KAM2W is a 4000 Series digital ‘two wire’ vandal resistant speaker module which has been specifically
developed for the Videx VX2200 (two wire audio and six wire video) bus systems. This module offers the same
features as the VR4KAM with the addition of being able to connect up to 23 individual buttons using the vandal
resistant VR4KBM button expansion modules.
Art.
SPEAKER UNIT MODULES FOR “4+1” AUDIO DOOR ENTRY AND VIDEO DOOR ENTRY SYSTEMS
VR4KAM-0
0 call push button.
VR4KAM-1
1 call push button.
VR4KAM-2
2 call push buttons.
VR4KAM-3
3 call push buttons.
VR4KAM-1NP
1 call push buttons with name plate holder.
VR4KAMK-1NP
1 call push buttons with name plate holder. Specific for audio kits and video kits.
Art.
SPEAKERUNITMODULES FORVX 2200DOOR ENTRY SYSTEMS (2WIRE AUDIOAND6WIRE VIDEO)
VR4KAM2W-0
0 call push button.
VR4KAM2W-1
1 call push button.
VR4KAM2W-2
2 call push buttons.
VR4KAM2W-3
3 call push buttons.
VR4KAM2W-1NP
1 call push buttons with name plate holder.
4000 Series Vandal Resistant range
Modular System
Art.
CAMERA MODULES FOR VIDEO DOOR ENTRY USING COAX OR
BALANCED VIDEO SIGNALS
VR4KCMC
Day/night colour camera with infrared LED’s.
VR4KCMCW
Wide Angle Day/Night colour camera with infrared LED’s.
To order the Wide Angle camera add “/wide” to the code.
CAMERA MODULES
The vandal resistant line of the 4000 Series modules consists of 1 camera module: VR4KCM.
The Art. VR4KCM can be used in video video door entry systems: traditional (combined
with Art. VR4KAM), VX2200 (combined with Art.V R4KAM2W) or Videokit (combined with
Art. VR4KAMK).
The module built-in camera is CCD type with infrared illumination LED and it is available in 2 models depending on
the type of camera used: colour Day/Night or colour Day/Night Wide Angle cameras.
In the firs type the camera has an horizontal and vertical adjustment (10 degrees) while theWide Angle camera type
is fixed with ahorizontal angle of 170 degrees.
The camera can be set for video composite signal ( coax cable) or for the balanced one (twisted pair wire).
