Standard
Art. 4212V + Art. 4882
Art. 4212RV + Art. 4882
135
280
44
9
61
9
45
84
GENERAL CATALOGUE
4000 Series Vandal Resistant range
Modular System
Art.
DIGITAL CALL PANELS FOR VX2200 DIGITAL SYSTEMS (2 WIRE BUS AUDIO, 6 VIDEO)
4212V
4000 Series Vandal resistant range (front plate in brushed stainless with 2mm thickness) digital call
panel for Videx VX 2200 digital systems (2 wire BUS audio, 6 wire BUS video). This panel is compat-
ible with the 4000 Series modular system and has the size of two 4000 Series modules.
Complementing all digital door panels manufactured by Videx is the ability for all users to have
their own unique access code (each apartment can have more than one access code). The access
code can have up to six digits and is blind to onlookers. Also,integrated into the panel is a proximity
reader enabling allowing a number of proximity fobs to be stored and used individually or in com-
bination with the access code to enter the building. In addition to the speaker unit functions, the
panel includes a 128 x 64 pixel graphical LCD display blue back lit (to provide visual and text mes-
sages in multiple languages guiding a visitor through the panel operation) plus a keypad with 18
blue back lit buttons 6 of which are alpha buttons (A..F), 10 are numeric buttons (0..9) plus “ENTER”
and “CLEAR” buttons. The tenants can be called by dialling the relevant apartment code.
To complement the visual messages provided from the display, the panel has the speech board
facility (optional chip installation) to supply audio messages concerning the system operation. The
built-in camera is a colour CCD wide angle day/night camera with IR illumination LED’s (the day/
night camera provides the best quality of view in any light condition and the wide angle camera
provides a viewing angle of 170 degrees). The camera can be set to work with composite video
signal (coax cable) or balanced video signal (one twisted pair). Interfaces include a Wiegand output
(for systems based on this interface) plus two serial interfaces (USB and RS-485) both allow for
programming and event logging. The programming menu and the setup menu are protected by
two passwords with different login levels (the engineer password that grants full access and the
system administrator password that is limited to some specific settings) while if you operate from a
PC an “Engineer’s Password” is requested to program the unit. A “Trade Code” function is available
(for periodic visitors) enabled by the specific input or by programmable time band and “Direct Call
Mode” for small installations (up to 10 apartments).
The memory capacity allows to store up to 998 users data, up to 2800 access codes, up to 2800
proximity keys and up to 4000 events. The front panel finish is brushed stainless steel while the
frame finishes are the standard offered in the 4000 Series.
4212RV
As Art. 4212V but using a keypad with 15 blue back lit buttons 3 of which are navigation buttons
used for the repertory name facility, 10 are numeric buttons (0..9) plus “ENTER” and “CLEAR” but-
tons. The tenants can be called by dialling the relevant apartment code or by searching the relevant
name using the repertory name function.
