GENERAL CATALOGUE
VX 2300
Digital System“Two wire” BUS video
VX2300 DIGITAL SYSTEM
Videx Vx2300 system is the latest digital system of the range which holds all the knowhow and expertise the com-
pany has gained in the field.
Thanks to the common bus, made of two non-polarized wires only, it is possible to carry out installations with one
or more entrances on the same floor, or with main and secondary entrances on different floors (up to a maximum
of 16 outdoor stations).
The outdoor stations specific for this system are those from the 4000 Series; this range includes both traditional
speaker units with inbuilt functional to digital (for installations up to 64 users) and digital panels (suitable for sys-
tems with more than 64 users).
Traditional speaker unit modules with functional to digital allow to connect traditional call buttons (max 64) to
the digital system, while digital panels, although they have the same size as two modules, can handle up to 800
apartements/1000 users.
Digital panels are available for both audio and video versions.
Digital panels , which allow to have small size outdoor stations, (2 modules for 4000 Series audio and audio/
video systems), can also work as access control devices, ( each apartment/user recorded in memory a unique a
code for “door open”), and other functions can give indications about the system working, such as speech board
(a voice guidance helps you about the operations you are making), or messages on the display, or the repertory
name facility (“R” version digital panels allow you to search for the name you whish to call through their special
research buttons).
The programming of these digital panels can be done both through their keypad and through a PC (using a pro-
gramming software and a cable).
Indoor units can be selected from a large range of intercoms and videophones for VX2300 digital system, that is
3000, 5000 Series and even the brand new 3600 Series.
Videx Vx2300 digital system is always expanding and updating, among the new units for this system you can find
Art. 3686, a new colour videophone from the 3600 Series.
Also, a complete range of accessories are available for the VX2300 digital system such as: Bus relay (that works as
a service relay in order to obtain up to 8 additional services or as sounder extension in order to connect external
sounders for calls ), bus amplifier ( to extend the distance covered by the installation by amplifying the bus line),
entrances switch Art. 2301N ( to combine up to 4 entrances on the same floor, and up to 8 by using 2 units),
block exchanger (which allows to carry out installations with main and secondary entrances) and interface for
Art. 380 ( which allows to answer the calls coming from the outdoor station with a normal phone).
MAIN FEATURES:
-- 2 wire none polarity conscious BUS
-- Distance up to 50 meters using standard telephone cable and up to 200 meters usingVidex supplied cable. (it is
meant as the maximumdistance between the power supply and the furthest outdoor station or videophone).
-- Multiple entrance systems with up to 16 audiovideo door panels among main and secondary entrances
(not exceeding a max number of 8 door panels on the same level).
-- Digital or functional door panels.
-- All digital door panels incorporate speech annunciation of call progress and error messages and the ability for all
users to have their own unique access code. The access code can have up to six digits and is blind to onlookers
(panels are programmable from PC or door panel).
-- System size up to maximum 100 devices (intercom/videophone) for installations with main entrances only or
100 devices for each block for installations with main and secondary entrances (Max 8 block exchangers in
the same system for a max total of 800 devices).
-- Up to 4 devices (intercom/videophone) in the same apartment (the maximum device amount allowed must
not be exceeded).
-- Intercommunication allowed between devices within the same apartment or between devices in different
apartments.
-- Local door bell facility.
-- Active video isolation splitter.
-- Bus relay module for extra services (up to 8) or to connect to extension sounder.
-- Telephone interface.
-- Block exchanger for installations with main and secondary entrances.
-- Bus booster.
-- Electric lock or other devices powered from the door panel.
