GENERAL CATALOGUE
VX 2300
Digital System“Two wire” BUS video
MAIN COMPONENTS
Art. 4302NV, 4302NRV, 4302N,4302NR - Digital Panels
Digital panels for the VX2300 are built into the 4000 Series modular frames (standard size 2 modules). The panels, in addition to
the speaker unit, includes a 2 line x 16 character LCD display with back lighting, keypad illumination and have a 15 (panel with
repertory name facility) or 18 push button keypad depending on panel version. Video versions include CCD camera and are
complete with subject illumination infrared LED’s (white light).
There are 2 models available with the following camera options: colour Day/Night or colour Day/Night withWide Angle camera.
In the first model the built-in camera has horizontal & vertical adjustment of 10 degrees while with theWide Angle the camera is fixed
but the field of view is 170 degrees. The camera can be set to work with composite video signal (coax cable) or balanced video signal
(one twisted pair).
To order the Wide Angle camera add “/wide” to the code.
Both audio and video panels have an input for external camera: in video panels it is possible to choose the main camera (the
camera which sends the video signal while calling) the user can commute the picture to the other camera anyway. VX2300
digital door panels have speech annunciation of the calls progress and error messages to assist the visitor and incorporate a
“coded access” facility for all users. All panels have a trade code plus a number of additional facilities, the “R” version door panels
incorporate a name search facility.
All digital panels are able to store up to 1000 user’s data, so the same apartment can be associated with more users (i.e. a profes-
sional user can be stored two times in the panel’s memory: once with the name of his company and once with his name per-
sonal). For each panel version, the optional speech board can be requested: the visitor is assisted by vocal messages during call
operations (available languages English, Portuguese, Croatian - other languages available on request for 3 panels as minimun
order).
Front panel finishes are the same as for the standard 4000 Series modules: mirror stainless steel (standard), anodized aluminium
and high polished brass.
Art. 4303N-0,1,2 - Speaker Unit with functional to digital interface module.
The Art. 4303N speaker unit can be used in place of digital door panels. The Art. 4303N is built into a single 4000 Series module and
includes the digital interface allowing the connection of up to 64 individual push buttons using the standard 4000 Series button expan-
sionmodules (Art. 4842, 4843, 4844 or 4845). The Art. 4303N is available with 1 button, 2 button or no buttons. Front panel finishes are
as per 4000 Series modular.
Art. 4330N - Camera Module
The Art. 4330N is housed in a single 4000 Series module. The built-in camera is CCD type with infrared illumination LED.
Are available in 2 models depending on the type of camera used: colour Day/Night or colour Day/Night Wide Angle cameras. In the
first type the camera has an horizontal and vertical adjustment (10 degrees) while theWide Angle camera type is fixedwith a horizon-
tal angle of 170 degrees.
The Art. 4330N has an external camera input that can be switched from a videophone connected to the system.
Front Panel finishes are as per 4000 Series modular.
Art. 317N - 4 way BUS distribution Box
The Art. 317N connects to the 2 wire BUS and allows 4 units (audio-intercoms or videophones) to be connected. One Art. 317N
required for every 4 units connected on the system.
Should a fault occur on an audio-intercom or videophone the Art. 317N will isolate all 4 units connected to it with no detrimen-
tal effect to the remainder of the system. Art. 317N is housed in a wall mounting plastic box 70 x 110 x 30mm.
Art. 318
Art. 318 is a 2 ways passive line bus distributor, it can be used in smaller systems where the distance between the outdoor sta-
tion and the furthest monitor is no more than 70mt. It is housed in a 50X60X20 mm plastic box which is for surface mounting.
Art. 2301N
Art. 2301N is the replacement for the Art. 2301/4 and 2301/8 entrance exchange units. The Art. 2301N will control 4 entrances
(up to 8 entrances if 2 x Art. 2301N’s are used). Each entrance can have its own video signal level set to cater for varying dis-
tances, the unit is housed in a 9 module DIN A type box and can be surface or DIN rail mounted.
Art. 2321N - Power Supply
Power supply for smaller systems with 1 door panel and a maximum of 20 audio-intercoms or videophones. The unit is housed
in a 9 module DIN box which can be rail or wall mounted.
