SE
12V
AC
ART.380
PowerSupply
Alimentatore
Art.520M
2
4
1
2
3
4
5
PowerSupply
Alimentatore
Art.520M
4
3+5
SE
12V
AC
2
VIDEX
3+1
2
2
CO.LINE
230Vac
3+1
3+1
VIDEX
VIDEX
3+1 3+1
VIDEX
3+3
3+1
ART.380
2
2
CO.LINE
230Vac
Art. 520M
Art. 520M
103
GENERAL CATALOGUE
Telephone systems
Telephone interfaces
Art.
TELEPHONE INTERFACES
380
The 380 (in A type DIN box 9 modules) telephone interface enables a conventional telephone to be con-
nected to a Videx audio or video door entry system. Thanks to the Art. 380, the telephone can work as a
standard intercom (to answer calls coming from the outdoor station and open the door) and as a stand
ard telephone (to receive and make calls from/to company line). In addition to the previous features, the
Art. 380 allows activation from the telephone two additional relay outputs, allows diverting a door panel
call to a pre-programmed telephone number or to a second telephone number if the first is busy etc.
The telephone used can be tone or pulse dial, traditional or DECT cordless.
The Art. 380 can be used in any VIDEX audio/video door entry system (in VX2200 and VX2300 systems
are required additional interfaces).
