GENERAL CATALOGUE
VX 2200
Digital System“Two wire” BUS audio - “Six wire” BUS video
MAIN COMPONENTS
Art. VX4202, 4202V, 4202R, 4202RV - Digital Front Panels
4000 Series modules are available in both audio and audio/video and are built into double 4000 Series modules and have
numeric keypads and 8 alpha buttons (VX4202, 4202V) or a numeric keypad with 3 “Repertory Names” navigation buttons
(VX4202R,4202RV), 2 x 16 character LCD display and speaker unit. Using the VX2207 programming kit which includes software
and a connection cable the digital front panels can be fully programmed using a PC.
All digital panels are able to store up to 1000 user’s data, so the same apartment can be associated with more users (i.e. a professional
user can be stored two times in the panel’s memory: once with the name of his company and once with his name personal). For each
panel version, the optional speech board can be requested: the visitor is assisted by vocal messages during call operations (available
languages English, Portuguese, Croatian - other languages available on request for 3 panels as minimun order).
These units will work with the 900, 3000, 3600, 5000, 6000 and Kristallo Series intercom and videophones and with the low cost
Art. 3161B/3162B intercoms.
4000 Series digital panels are available in stainless steel (/S) or anodized aluminium (/A).
Art. 4212V, 4212RV, 4212V/F, 4212RV/F, 4212V/SA, 4212RV/SA - Digital Front Panels
4000 Series Vandal resistant range (front plate in brushed stainless with 2mm thickness) digital call panel for Videx VX 2200
digital systems (2 wire BUS audio, 6 wire BUS video). This panel is compatible with the 4000 Series modular system and has the
size of two 4000 Series modules.
Complementing all digital door panels manufactured by Videx is the ability for all users to have their own unique access
code (each apartment can have more than one access code). The access code can have up to six digits and is blind to onlook-
ers. Also,integrated into the panel is a proximity reader enabling allowing a number of proximity fobs to be stored and used
individually or in combination with the access code to enter the building. In addition to the speaker unit functions, the panel
includes a128 x 64 pixel graphical LCD display blue back lit (to provide visual and text messages in multiple languages guiding
a visitor through the panel operation) plus a keypad with 18 blue back lit buttons 6 of which are alpha buttons (A..F), 10 are
numeric buttons (0..9) plus “ENTER” and “CLEAR” buttons. The tenants can be called by dialling the relevant apartment code.
To complement the visual messages provided from the display, the panel has the speech board facility (optional chip instal-
lation) to supply audio messages concerning the system operation. The built-in camera is a colour CCD wide angle day/night
camera with IR illumination LED’s (the day/night camera provides the best quality of view in any light condition and the wide
angle camera provides a viewing angle of 170 degrees). The camera can be set to work with composite video signal (coax ca-
ble) or balanced video signal (one twisted pair). Interfaces include a Wiegand output (for systems based on this interface) plus
two serial interfaces (USB and RS-485) both allow for programming and event logging. The programming menu and the setup
menu are protected by two passwords with different login levels (the engineer password that grants full access and the system
administrator password that is limited to some specific settings) while if you operate from a PC an “Engineer’s Password” is
requested to program the unit. A “Trade Code” function is available (for periodic visitors) enabled by the specific input or by
programmable time band and “Direct Call Mode” for small installations (up to 10 apartments).
The memory capacity allows to store up to 998 users data, up to 2800 access codes, up to 2800 proximity keys and up to 4000
events. The front panel finish is brushed stainless steel while the frame finishes are the standard offered in the 4000 Series.
Art. VX4203-0,1,2 - Speaker unit module with functional/Digital Interface
This unit is built into a single 4000 Series module, it includes the speaker and interfaces to the digital bus. Up to 64 push buttons can
be added to the interface using the Art. 4842, 4843, 4844, 4845 etc (the 4203 is available with either 1 button, 2 buttons or no buttons).
Art. VX4283-0,1,1D - Speaker unit module with functional/Digital Interface and built-in camera
The 4283 unit is an intelligent front panel based on a “6 wire” BUS intercom system that enables the connection of traditional
push buttons. This unit is housed in a single 4000 Series module and incorporates the functional interface connections from
functional to digital bus, the speaker module with 0, 1 or 2 call buttons also includes a high quality CCD Camera and infrared illu-
mination LED’s. In addition to conventional acoustic signals, the 4283 speaker unit gives visual indication relevant to the system
operation by the 4 LED’s on the front panel. For each version (0, 1 or 2 buttons) there are 2 models available with the following
camera options: colour Day/Night or colour Day/Night with Wide Angle camera.
In the first model the built-in camera has horizontal & vertical adjustment of 10 degrees while with the Wide Angle the camera
is fixed but the field of view is 170 degrees.
The camera can be set to work with composite video signal (coax cable) or balanced video signal (one twisted pair). Available in all
the 4000 Series finishes. This device enables the connection of up to 32 functional push buttons using standard 4000 Series extension
module panels Art. 4842, 4843, 4844, 4845 and relevant double button version 4842D, 4843D, 4844D and 4845D. The 4283 can work
with any intercom and videophone available for the VX2200 from 900, 3000, 3600, 5000, 6000 and Kristallo Series range.
To order the Wide Angle camera add “/wide” to the code.
Art. VR4KAM2W-0,1,2,3 - Speaker unit module with functional/Digital Interface vandal resistant line
The VR4KAM2W is a 4000 Series digital ‘two wire’ vandal resistant speaker module which has been specifically developed for the
Videx VX2200 (two wire audio and six wire video) bus systems. This module offers the same features as the VR4KAM with the
addition of being able to connect up to 23 individual buttons using the vandal resistant VR4KBM button expansion modules.
