GENERAL CATALOGUE
VX 2200
Digital System“Two wire” BUS audio - “Six wire” BUS video
VX2200 DIGITAL SYSTEM
“2 WIRE BUS”
Videx VX2200 digital system is the most “versatile” system in the range, because it is flexible enough to cater for a
variety of installations: from 1 way systems to larger systems that include a maximum of 1000 apartments.
This system uses a two wire common bus for audio installations and 6 wires for audio/video installations. Outdoor
stations can be selected from the 4000 or 8000 Series: both series have traditional speaker units with an inbuilt
functional to digital interface (for installations up to 64 apartments) and digital panels (suitable for systems with
more than 64 apartments).
Speaker units with functional to digital interface allow to connect traditional call buttons to the digital systemwhile
digital panels, although have the same size as two modules, can handle up to 1000calls (1000 apartments/users).
4000 Series digital panels are available for both audio and video versions, while 8000 Series panels can only require
an additional camera module for video systems.
Digital panels, which allow to have small size outdoor stations (2 modules for 4000 Series audio and audio/video
systems, and 2 or 3 modules for 8000 Series audio and audio/video systems), can also work as access control devices
(the latest panels of 4212 range, that includes also the RFID technology, allow for each apartment/user to record one
or more access code and/or one or more proximity key in order to open the door. This range of panels has also the
logging function on serial output) and include other functions such as speech board (a voice guidance helps you
through the calls progress) or messages on the display or the repertory name facility (“R”version digital panels allow
you to search for the name you wish to call through their special search buttons).
The programming of these digital panels can be done both through their keypad and through a PC (using a pro-
gramming software and a cable).
Indoor units can be selected from a large range of intercoms and videophones for VX2200 digital system, including
the 900, 3000, 5000, 3600, 6000 and Kristallo Series.
Videx VX2200 digital system is continually expanding and updating, among the new units for this system you can
find the KRISTALLO Series with the latest Art.KRV778 which is a Hands Free videomonitor using 7” full colour active
matrix LCD display with OSD and capacitive touch sensitive buttons or the latest models Art.6072 and 6272 from the
low cost, easy to use, compact and minimalistic design 6000 Series.
Also, a complete range of accessories is available for the VX2200 digital system such as: digital concierge ( which
allows to handle all calls externally, alarms and the intercommunication among indoor stations), extension sounder
( that extends the area within the melody tone of the call can be heard), Bus relay ( to activate services related to an
alarm or a specific call), telephone interface (to answer the call through the phone) and the new block exchanger
Art. 2206N which allows to carry out installations up to 1000 users/ apartments with one entrance or with main and
secondary entrances (in this case you can connect up to 180 users to each secondary entrance/block , not exceeding
the total number of 1000 users), secondary entrances can work simultaneously as separate installations.
Among all the solutions that Videx VX2200 system offers, it is also possible to carry out low cost intercom systems
without digital concierges, up to 255 apartments, by using 3000 Series intercoms (Art. 3161B and 3162B).
If you use a 900 series unit you cannot install in the same system indoor units from other series, while units from
3000 Series (316X items excluded), 3600, 5000, 6000 and Kristallo Series can be mixed in the same system.
MAIN SPECIFICATIONS:
-- Ease of installation.
-- Ease of programming (through front panel keypad or PC).
-- “2 wire” common bus for intercom systems, “6 wire” for videophone systems with centralized power supply.
-- Excellent quality audio and video signals.
-- Privacy of speech and lock release.
-- Direct calling of up to 998 flats with intercoms/videophones (except 900 Series) and 2206N units (180 flats
each 2206N) or up to 255 flats only with special intercoms Art. 3161B and 3162B.
-- Multi level facility.
-- Multi entrance facility (up to 10 entrances for each level).
-- All peripherals are intelligent and can be connected directly to the bus.
-- Back up battery facility.
-- Digital Front Panel with numerical keypad and display with the ability for all users to have their own unique
access code. The access code can have up to six digits and is blind to onlookers.
-- Functional panel interface available.
-- Digital concierge facility.
