160
280
280
200
320
400
400
400
135
270
270
405
44
17
44
17
44
17
44
17
44
17
44
17
80
80
135
80
135
80
Art. 4881
Art. 4882
Art. 4883
Art. 4886
Art. 4889
Art. 4884
87
GENERAL CATALOGUE
SURFACE MOUNTING UNIT
The surface mounting units are available in 1, 2, 3, 4, 6 and 9 module versions which include:
-- The surface box to fix to the wall with the screws provided.
-- The module support frames are provided with waterproof gaskets and security screws. When surface mount-
ing 4, 6 or 9 module versions, the support frames provided are 2 x two module, 2 x three module and 3 x
three module versions.
The only available finish for the back box is embossed metallized gun-metal grey.
ANTITAMPERING
An anti-tamper switch Art. 482 is available for the 4000 Series surface mounting boxes.
Art.
MODULES SIZE WxHxD (mm)
4881
1
135x160x44
4882
2
135x280,2x44
4883
3
135x400,4x44
Art.
MODULES SIZE WxHxD (mm)
4884
4
270x280,2x44
4886
6
270x400,4x44
4889
9
405x400,4x44
4000 Series
Modular System
