GENERAL CATALOGUE
VX 2200
Digital System“Two wire” BUS audio - “Six wire” BUS video
Art. VR5178 - Intercom
Same features of Art. 5178 but vandal resistant version: the “service” button that is missing, is replaced by the “privacy” button
that works also as“service”button. Adjustments and programmable functions are the same but are carried out in a different way.
Vandal resistant version is for flush mount. This version is made from a brushed stainless steel plate, 2.5mm thickness, to which,
in the back side, is secured the intercom circuitry. The intercom includes the flush mounting box comprised of fixing screws.
Art. KRA78 - Intercom
Flush mount hands free audio intercom. All buttons use capacitive touch sensor technology, 4 of these buttons have multiple
direct functions such as “answer/end conversation/recall/simplex conversation”, “door open”, “privacy/call reject/programming
menu access” (programmable duration) and “service” button. 3 LED’s give visual indication of operations while the other 5 but-
tons allow navigation of the programming menu’s and the setting of volumes.
It is possible to program the melody (9 available), the number of rings (max 9) and the privacy service duration (max 20 hours).
Also includes a local bell function.
Available in black (add to the product code “/B”) or white (add to the product code “/W”) finishes.
Art. KRA76 - Intercom
As Art.KRA78 but surface mount version with telephone handset.
Art. 3471 - Videophone
Videophone, for coax and non coax video systems, using a 3.5” LCD TFT colour monitor, with “door open” and “camera recall”
push buttons plus 3 service buttons and an “ON” LED. Programmable melody and number of rings. Controls: 3 levels of call
tone volume (both main and local), contrast and brightness.
Art. 3476 - Videophone
As Art. 3471 but with 2 service push buttons plus electronic “ON-OFF” timed privacy push button, “DOOR OPEN” and“PRIVACY
ON” LED’s.
Art. 3676 - Videophone
Videophone using 3.5” full colour active matrix LCD monitor for VX2200 digital video door entry systems using composite (coax
cable) or balanced (twisted pair) video signal. Including 3 buttons “camera recall”, “door-open/concierge-call”, “privacy/service”
plus 3 LED’s* for visual indication of all functions. Adjustments & programmable options: call tone volume on 3 levels (low, me-
dium, high), picture brightness and hue, call tone melody, number of rings, video mode, privacy duration and address.
Also includes a local bell function and extension sounder output.
The Art. 3676 is surfacemount and requires the Art. 5980 connection board and wall mounting plate. Except for the service button, all
other connections are the same as the Art. 5478 or SL5478N 5000 Series videophones but doesn’t require a permanent 12V.
Art. 3678 - Videophone
“High End” Videophone (with hands free facility) using 3.5” full colour active matrix LCD OSD monitor for VX2200 digital video
door entry systems using composite (coax cable) or balanced (twisted pair) video signal. Including 3 buttons “door-open/con-
cierge-call”, “answer/camera recall/’push to talk”, “privacy/call reject/service” plus 3 LED’s* for visual indication of all functions.
Adjustments & programmable options (through OSD menu): loudspeaker volume, call tone volume, picture contrast, brightness
and hue, privacy duration, call tone melody, number of rings. Address and video mode are programmable through 2 dip-switch
banks. Also includes a local bell function.
The Art. 3678 is surface mount and requires the Art. 5980 connection board and wall mounting plate. Except for the service but-
ton, all other connections are the same as the Art. 5478 or SL5478N 5000 Series videophones.
Art. SL5478N - Video monitor
Hands free video monitor using 3.5” full colour active matrix LCD monitor, with “door open/concierge call” , “answer/camera
recall”, “privacy on/off” buttons all with LED* indication and 3 additional service buttons.
Controls: loudspeaker volume, call tone volume, picture brightness and hue.
Programmable number of rings, melody, privacy duration and video mode.
Electronic call tone generated by the unit plus active low inputs for local bell and alarm.
Art. VR5478 - Video monitor
Same features of Art. 5478 but VANDAL RESISTANT version. Programming and adjustments are carried out through a contextual
OSD menu. Only for flush mount.
Art. 6072 - Videophone
Surface mount videophone incorporating a 2.4” Hi-Res full colour active matrix LCD monitor, with “camera recall”, “door open/
concierge call”, 2 “service” buttons plus 2 LED’s* one for generic use (door opening usually) and one to indicate privacy service
enabled. Programmable settings: video mode (coax or balanced), melody and number of rings.
Adjustments: call tone volume (2 levels plus privacy position), microphone volume, picture hue, contrast and brightness.
