Art. 3686 - Videophone
Videophone using 3.5” full colour active matrix LCD monitor for VX2300.
Including 3 buttons “camera recall”, “door-open/intercommunicating call”, “privacy/service” plus 3 LED’s for visual indication of
all functions. Adjustments & programmable options: call tone volume on 3 levels (low, medium, high), picture brightness and
hue, call tone melody, number of rings, privacy duration and address.
Also includes a local bell function.
The Art. 3686 is surface mount and requires the Art. 5980 connection board and wall mounting plate.
Art. SL5488N - Hands free video monitor
Hands free video monitor using 3.5” full colour active matrix LCD monitor, with “door open/concierge call” , “answer/camera
recall”, “privacy on/off” buttons all with LED* indication and 3 additional service buttons.
Controls: loudspeaker volume, call tone volume, picture brightness and hue. Programmable number of rings, melody, privacy
duration and video mode. Electronic call tone generated by the unit plus active low inputs for local bell and alarm.
Art. 6286 - Videophone
Surface mount videophone using 3.5” full colour active matrix LCD monitor for VX2300. Including 4 buttons “service”, “privacy/
bus relay activation”, “door- open/intercommunicating call” and “camera recall” plus 3 LED’s* for visual indication of all
functions. Adjustments & programmable options: call tone volume on 3 levels (low, medium, high), picture hue, brightness
and contrast, call tone melody, number of rings, privacy duration and address. Also includes a local bell function.
Art. 6388 - Hands free videophone
Surface mount hands free intelligent Videophone using 3.5”full colour active matrix LCDmonitor for VX2300. Including 4 buttons
“service”,“privacy/bus relay activation”,“door- open/intercommunicating call”and“camera recall”plus 3 LED’s* for visual indication of
all functions. Adjustments & programmable options: call tone volume on 3 levels (low, medium, high), picture hue, brightness and
contrast, call tone melody, number of rings, privacy duration and address. Also includes a local bell function.
Art. KRV88 - Hands free video monitor
Flushmount intelligent Hands free videomonitor for the VX2300 digital systemusing 3.5”OSD full colour active matrix LCDmonitor,
with touch sensitive buttons for“door open / service”,“answer/camera recall”,“privacy/bus relay”plus 5 navigationmenu buttons and
3 LED’s related to the videophone operation.
Additional features include a real time clock, a temperature sensor and a serial RS232 port for future integration with home
automation systems.
Art. KRV86 - Videophone
As Art. KRV88 but surface mounting version with handset for conventional use in addition to the hands free mode.
Art. KRV788 - Hands free video monitor
Intelligent handsfree video monitor using 7”TFT Hi Resolution colour monitor with OSD (On Screen Display) technology and 8
capacitive touch sensitive buttons for VX2300 digital system.
2 LED’s* give visual indication about door open and privacy service.
Recall and intercommunication call functions, privacy and secondary service, concierge call and alarm
signal (if available), push to talk speech mode and temperature sensor.
Programmable options: loudspeaker and call tone volume, picture contrast, brightness and hue, date
and time, privacy and secondary service time, temperature scale, call tone melody and number of
rings, ID number, text and background colours.
* The operation of some LED’s and the functions described may require additional cabling
ACCESSORIES
Art. 2207 - PC interface cable and Programming Software
This kit enables the full programming of the Art. VX2202M, 2202MR, 2210-1, 4202, 4202V, 4202R, 4202RV, 8202, 8202R, 4302N,
4302NR, 4302NV, 4302NRV directly from a PC.
