GENERAL CATALOGUE
CODE-LOCKS MODULES FOR 8000 SERIES MODULAR SYSTEM
These units have been designed to compliment the “Series 8000”audio and video modules. The units are available
in 2 or 3 relay versions, with 2 or 100 code options and with optional keypad illumination lamp. All versions have
2 command relay inputs. Front plates are available in stainless steel (suffix the product code with /S) or aluminium
(suffix the product code with /A).
Working Voltage:
12/24Vac/dc 1 VA
Working Temperature:
-10 +50°C
Relay contacts:
24Vac/dc 3A
CODELOCKS MODULES FOR 4000 SERIES MODULAR SYSTEM
These units have been designed to complement the 4000 Series audio and video modules.
Are available in 4 different models: 3 for the standard line and 1 for the vandal resistant line. The modules for the
standard line have the same look but can be identified by the number of built-in relays and managed access codes.
The Art. 4801, having a serial RS-485 interface, offers the facility to be connected to the remote control units
Art. VX1050 and Art.VX 1052. The programming of the modules can be carried out through the module keypad
or, for the Art. 4801, through a pc software (Art. 4829 CD programming software plus connection cable).
Finishes as provided for 4000 Series modular system.
Working Voltage:
12/24Vac/dc 1 VA.
Working Temperature:
-10 +50°C
Relay contacts:
24Vac/dc 3A
Art.
DESCRIPTION
8800
Codelock module, 2 code/2 relay output.
8900
Codelock module, 100 code/2 relay out put.
Art.
DESCRIPTION
4800
Codelock module 3 codes / 3 relays.
4801
Codelock module up to 3.000 codes / 2 relays (RS-485 facility).
4900
Codelock module 100 codes / 3 relays.
VR4KCLM
As Art. 4800 but vandal resistant line.
Access Control
