GENERAL CATALOGUE
LOW COST SERIAL CODELOCKS
Having the same appearance as the “stand-alone” version, these are available for flush or surface mounting, with
the front panels available in two different finishes: aluminium gold anodized (add “/G” to the product code when
ordering) or aluminium silver anodized (add “/A” to the product code).Working temperature -10 +50°C.
SERIAL CODELOCK MODULES FOR 4000 SERIES MODULAR SYSTEM
These units have been designed to compliment the 4000 Series audio and video modules. The Art. 4801 can op-
erate in stand-alone mode but having a serial RS- 485 interface, offers the facility to be connected to the remote
control units Art. VX1050 and Art. VX1052. Finishes as provided for 4000 Series modular system
Working Voltage:
12/24Vac/dc 1 VA
Working temperature:
-10 +50°C.
Relay contacts:
24Vac/dc 3A
Art.
DESCRIPTION
VX1011
Keypad module with serial connection compatible with the following Videx Control Units: VX1000,
VX1000B, VX1010-1 or VX1010-2.
VX1011S
As above but surface mounting.
Art.
DESCRIPTION
4801
Codelock module up to 3000 codes / 2 relays (RS-485 facility).
Access Control
