Art. VX955/C
Art. VX955/T
Art. VX 1010-2
112
GENERAL CATALOGUE
CONTROL UNITS FOR SERIAL CODELOCKS
All serial codelock units require a remote VIDEX control unit.
Control Units are identified by memory capacity (number of access codes that can be stored), the number
of relay outputs (with C/NC/NO contacts) and the operating mode. The control unit is programmed via the
keypad to which it is connected. The programming allows for the storage of access codes and the setting of
the relay operating times.
Access to the programming menu is password (PIN) code protected (maximum 8 digits) and can be customized
by the end user.
Serial connection between units uses 3 standard wires with a maximum distance of 600mts.
ACCESS CONTROL SYSTEMS USING PROXIMITY KEY READERS
“VproX” control units are available in five different sizes, allowing greater flexibility in the design and implementa-
tion of access control systems. A system will include a control unit, one or more key reader, power supply and as
many proximity keys as required. VproX” access control systems can be used from 1 door 20 user installation up to
20 main doors and 99 apartment doors with 4000 users.
Art.
CONTROL UNIT FEATURES
VX1010-1
Control Unit with door open/additional service function, with 1 access code, 1 relay output with the
option to control up to 2 serial keypads in parallel using keypad types: VX1001, VX1011, VX1020
and VX1021.
Housed in a standard 5 module A type DIN box (87.50mm).
Working Voltage:
12/24Vac/dc 2VA max
Working temperature: -10 +50°C
VX1010-2
Control Unit with door open/additional service function, with 9 access codes and 2 relay outputs.
The unit will control up to 2 serial keypads in parallel, using keypad types: VX1001, VX1011, VX1020
and VX1021.
Housed in a standard 5 module A type DIN box (87.50mm).
Working Voltage:
12/24Vac/dc 2VA max
Working temperature:
-10 +50°C
Art.
PROXIMITY KEYS
All proximity keys use a 32 bit code (with over 4 billion combinations) and are available in two
different formats: card and tags.
VX955/C
Proximity key built into a PVC card, badge size (ISO standard 85,6x54x0,76). colour: gloss white,
compatible for silk screen printing. 32 bit code and a reading distance up to 50mm (usingVidex readers).
VX955/T
Proximity key built into a plastic key-holder (fob), diameter 36mm and thickness 5mm. colour: grey,
with Videx logo. 32 bit code and reading distance up to 20mm (using Videx readers).
Access Control
