Art. 849P/G
Art. 849P/W
Art. 849Z/G
Art. 849Z/N
113
GENERAL CATALOGUE
PROXIMITY KEY READER UNITS
VIDEX produce a wide range of proximity key readers to meet all installation and market requirements. The range
includes: surface mounting readers in plastic or metal housings, flush mounting readers, reader modules for
8000 Series and “4000 Series”modular systems and reader modules for installation on third party products.
Art.
DESCRIPTION
849Z
Proximity key reader for VIDEX 32bit coded keys.
The circuitry is housed in a die-cast aluminium alloy enclosure (compact and robust) with a polycarbonate
window for the key reading area. The maximum reading distance is between 20 to 50mm depending on
the key type used. The unit gives visual (tri coloured LED in reader window) and audible signals (internal
buzzer) of operation. Connection from the reader to the “VproX” control unit requires a 5 wire cable for a
maximum distance of 200 meters.
The Art. 849Z is available in two different finishes: pearl nickel (to order add “/N” to the product code) or
dark grey (to order add “/G”) The key reader is supplied from the control unit and is provided with a hid-
den fixing plate for surface mounting and a 3mts 5 core cable.
Working temperature: -10 +50°C
Art.
SURFACE MOUNTING READERS
849P
The 849P is housed in an impact resistant ABS plastic housing and has the same features as the 849Z. The
units are available in two colours: white (to order add “/W” to the product code) or dark grey (add “/G”
to the product code).
Working temperature: -10 +50°C
Access Control
