GENERAL CATALOGUE
STAND ALONE READERS FOR 4000 SERIES MODULAR SYSTEM
The 4000 Series is continuously undergoing enhancements and improvement to current modules and introduc-
ing new modules to complement the range. Two new stand-alone proximity key reader modules have
been added to the range.
The appearance of these new modules is the same as the Art. 4849 but include a dry contact changeover relay.
The readers are available in two versions 100 and 1000 user. The 1000 user (Art. 4850/P) has an RS-232 and RS-
485 serial interface included and can be used standalone (Self contained) or as part of a network. Programming
of both units is carried out using the 4 buttons on the rear of the modules or additionally through a PC or the
network for the Art. 4850/P. Finishes as provided for 4000 Series modular system.
Working Voltage:
12/24Vac/dc 1 VA
Working temperature:
-10 +50°C
Relay contacts:
24Vac/dc 3A
Art.
READERS FOR 4000 SERIES MODULAR SYSTEM
4850
Stand-alone proximity key reader module with 1 relay, 100 users.
4850/P
Stand-alone proximity key reader module with 1 relay, 1000 users RS-
232 for programming, RS-485 serial interfaces which allows connection
to remote control units Art. VX1050 and Art. VX1052.
Art.
READERS FOR 4000 SERIES MODULAR SYSTEM
4849
Videx proximity reader built in to a 4000 Series module. Having the same features as the above
models. This unit combines a polycarbonate reader window. Finishes as provided for 4000 Series
modular system.
Working temperature -10 +50°C
VR4KVPM
As Art. 4849 but vandal resistant line
