Art. 849F
Art. VP/PM
Art. 8849
114
GENERAL CATALOGUE
Art.
FLUSHMOUNTING READERS
849F*
Proximity key reader having the same features as Art. 849 but using flush mounting support. The support
(made from impact resistant ABS plastic) is available in 2 different colours: white and dark grey (when or-
dering add suffix /W for white or /G for dark grey). The installation requires a standard 503 flush mounting
box (not provided).
Working temperature: -10 +50°C
*Painting of different colours shall be made by the customer: in this case order the unassembled version of the article.
Art.
PANEL MOUNTING UNIT
VP/PM
Proximity key reader head for panel mounting (or other third party support mounting), with polycar-
bonate window (40x40mm), protection box (55x55mm) and 35cm connection cable. Same features and
operation of other models.
4 fixing holes as shown in the drawing.
Working temperature -10 +50°C
Art.
READERS FOR 8000SERIES MODULAR SYSTEMS
8849
Videx proximity reader built in to a “Series 8000”module. Having the same features as the above models.
This unit combines a polycarbonate reader window with stainless steel or aluminium frame (when order-
ing add a suffix “/S” for stainless steel or “/A” for aluminium).
Working temperature -10 +50°C
Access Control
